200GBASE SR4 QSFP56 100m MPO Optical Transceiver
200G QSFP56 SR4 is a hot-pluggable 4 × 50Gbps multimode fiber optical module. This module integrates four parallel channels, each with a baud rate of 26.5625GBd. It can transmit a distance of up to 70 meters on OM3 fiber and up to 100 meters on OM4 fiber with FEC
Send Inquiry
Product Introduction
|
Part Number |
200G QSFP56 SR4 |
|
Form Factor |
QSFP56 |
|
Data Rate: |
200G |
|
Wavelength |
850nm |
|
Distance |
100M |
|
Connector |
MPO |
|
TX |
VCSEL |
|
RX |
PIN |
|
TX Power |
-6.5dBm ~4dBm |
|
RX Sensitivity |
-7.0dBm |
|
DDM |
Yes |
|
Warranty |
3 Years |
|
Commercial Temperature Range |
0°C~70°C |
|
Place of Origin |
Guangdong, China |
|
Application |
Telecommunication |
Packaging and delivery
Packaging Details
neutral packing, retail packing, plastic packing,carton box, etc
Selling Units:
Single item
Single package size:
20X15X6 cm
Single gross weight:
0.040 kg
Features:
- Hot PluggableQSFP56 form factor
- Built-in 200G PAM4 DSP
- Compliant with IEEE Std 802.3bs, IEEE Std 802.3cm
- Compliant with 200G-SR4 optical specifications
- Compliant with SFF-8679
- Compliant with CMIS4.0 Management interface specifications
- Digital Diagnostics Monitoring Interface
- 4x53.125Gb/s electrical interface (200GAUI-4)
- Reach up to 70m on MMF(OM3)
- Reach up to 100m on MMF(OM4)
- Single +3.3V power supply
- Case temperature range: 0 ~ +70℃
- Maximum power consumption 5W
- Single MPO12 connector
- RoHS-6 Compliant
- Power dissipation<6W
- TDEC<4.5dB
- Single MPO12 receptacle
