100G QSFP28 ER4+ 60km LC DDM Transceiver

Advantages

*Power consumption as low as 5.5W

*Demonstrated superior performance, quality and reliability in target switches

*The electrical interface complies with IEEE 802.3ba standard to achieve high-speed data transmission

*Conforms to QSFP28 MSA, hot swappable

*In line with the United States FDA Class I laser safety standards and RoHS regulations

*Digital optical monitoring, strong diagnostic capability

*Capable of reaching a distance of 60 km via G.652 single mode fiber without FEC



Applications

*Data Center Interconnect

*100G LWDM4 applications

*Infiniband EDR interconnects

*Enterprise networking



SPE	QSFP28 100G 1295-1310nm 60KM LC DDM
PN	QSFP28-ER4+
Form Factor	QSFP28
Max Data Rate	103.125Gbps
Wavelength	1295~1310nm
Max Cable Distance	60km
Connector	Duplex LC
Cable Type	SMF
TX Power	1 to 6dBm
Receiver Sensitivity	<-30dBm
Power Consumption	≤5.5W
Commercial Temperature Range	0 to 70°C (32 to 158°F)
DDM	Support
Bit Error Ratio (BER)	1.00E-12
Media	SMF
Transmitter Type	EML
Receiver Type	PIN
Power budget	31dB
DDM/DOM	Supported
Receiver Overload	6dBm
Standards	QSFP28 MSA IEEE 802.3ba RoHS-10 compliant
Modulation Forma	NRZ
Clock and Data Recovery	TX & RX Built-in CDR
Warranty	3 Years
