Advantages,
1.The speed is 100G, it comes with DDM and uses LC connectors.
2.Low power consumption, ≤3.5W, using CWDM DFB+PIN technology.
3. Suitable for campus network, data center and enterprise core layer.
4.It is compatible with more than 100 vendors.
5.QSFP28 supports hot-swappable MSA.
Standards
*Compliant to IEEE 802.3ba, IEEE 802.3bm,
*Compliant with QSFP28 MSA
*Compliant to SFF-8665, SFF-8636,
*Compliant with 100G CWDM4 MSA
|
SPE |
QSFP28 100G 1270-1330nm 2KM LC DDM |
|
PN |
QSFP28-IR4 |
|
Model Name |
QSFP28-IR4 |
|
Form Factor |
QSFP28 |
|
Data Rate |
103.125 Gbps (4x 25.78Gbps) |
|
Wavelength |
1271~1331nm |
|
Distance |
2km |
|
Connector |
Duplex LC |
|
Cable Type |
OS2 SMF |
|
Transmitter Type |
4x CWDM DML (DFB) |
|
Receiver Type |
PIN |
|
TX Power |
-6.5~2.5dBm |
|
Receiver Sensitivity |
<-11.5dBm |
|
Power Consumption |
≤3.5W |
|
Modulation Format |
NRZ |
|
DDM |
Support |
|
Bit Error Ratio (BER) |
5E-5 |
|
Warranty |
3 Years |
