SC UPC Fast Connector
SC embedded fiber optic connector quick connector cold, using tricyclic class A ferrule insertion loss, operability / reuse /stable performance, low cost, fast installation and so on. They don’t need to polishing, no epoxy. They could be installed in the field and make connection less than two minutes. Of course, It don’t need fused the fiber. Just some little tools enough, so it could save time and cost.
|
Polishing |
UPC |
|
Fiber Mode |
9/125μm Single mode |
|
Dimension |
50/53/60mm |
|
Return Loss |
UPC≥45dB |
|
Operating Temperature |
-40°C~+75°C |
|
Connector Type |
SC |
|
Ferrule |
Ceramic |
|
Cable Diameters |
0.9/2.0/3.0mm Simplex cable 2x3 FTTH Drop Cable |
|
Insertion Loss |
≤0.3dB(typical) ≤0.5dB(Max) |
|
Tension Strength |
≥50N |
|
Feature |
Price-Competitive60mm 55mm 53mm 50mm Singlemode SC UPC fiber optic fast installation connector |
|
Low Insertion Loss |
|
|
No epoxy and polishing required |
|
|
Quick and easy fiber termination |
|
|
Precision mechanical alignment insures low insertion loss |
|
|
Superior optical performance |
|
|
Streamlined component design, convenient operation |
|
|
Pre-installed, on-site assembly without end face grinding and consideration |
|
|
Uses proven, molded v-groove technologies |
Advantages
1.Advanced production and testing equipment
2.Professional manufacturer, 100% tested.
3.Full compliance with ISO 9001:2008 quality management system
4.Our company has experienced professional team
5.Provide reliable solutions and satisfactory services
6.Warmly services with careful attentions.
7.Can provide your specific inquiry within 24 hours.Advanced production and testing equipment
Applications
1. Distribution frames
2. Maintenance or emergency restoration of fiber networks
3.China Supplier Fiber Optical field Assembly 60mm SC UPC Fast Connector
4. Patch panels
5. FTTH
6. Field word
Hot Tags: sc upc fast connector, China sc upc fast connector manufacturers, factory, fast connector apc, sc apc lc upc, lc apc upc, Quick Connector Field Assembly, lc apc sc apc, lc upc apc
