10Gbs BIDI 1270 1330nm LC 20km SFP+
■This 1270//1330nm DFB 10Gigabit SFP+ transceiver is designed to transmit and receive optical data over single mode optical fiber for link length 20km.
■The BIDI SFP+ LR module electrical interface is compliant to SFI electrical specifications.The transmitter input and receiver output impedance is 100 Ohms differential.Data lines are internally AC coupled.The module provides differential termination and reduce differential to common mode conversion for quality signal termination and low EMI.SFI typically operates over 200 mm of improved FR4 material or up to about 150mmof standard FR4 with one connector.
Absolute maximum rating
|
Parameters |
Symbol |
Min. |
Max. |
Unit |
|
Power Supply Voltage |
VCC |
0 |
+3.6 |
V |
|
Storage Temperature |
Tc |
-40 |
+85 |
°C |
|
Operating Case Temperature |
Tc |
0 |
+70 |
°C |
|
Relative Humidity |
RH |
5 |
95 |
% |
|
RX Input Average Power |
Pmax |
- |
0 |
dBm |
Electrical characteristics
|
Parameter |
Symbol |
Min. |
Typical |
Max |
Unit |
Notes |
|
Data Rate |
|
- |
10.3125 |
- |
Gbps |
|
|
Power Consumption |
|
- |
1200 |
1500 |
mW |
|
|
Transmitter |
||||||
|
Single Ended Output Voltage Tolerance |
|
-0.3 |
- |
4.0 |
V |
|
|
C common mode voltage tolerance |
|
15 |
- |
- |
mV |
|
|
Tx Input Diff Voltage |
VI |
400 |
|
1600 |
mV |
|
|
Tx Fault |
VoL |
-0.3 |
|
0.4 |
V |
At 0.7mA |
|
Data Dependent Input Jitter |
DDJ |
|
|
0.10 |
UI |
|
|
Data Input Total Jitter |
TJ |
|
|
0.28 |
UI |
|
|
Receiver |
||||||
|
Single Ended Output Voltage Tolerance |
|
-0.3 |
- |
4.0 |
V |
|
|
Rx Output Diff Voltage |
Vo |
300 |
|
850 |
mV |
|
|
Rx Output Rise and Fall Time |
Tr/Tf |
30 |
|
|
ps |
20% to 80% |
|
Total Jitter |
TJ |
|
|
0.70 |
UI |
|
|
Deterministic Jitter |
DJ |
|
|
0.42 |
UI |
|
