10Gbps 1310nm 20km LC SFP+
The SFP+ transceivers are high performance, cost effective modules supporting data rate of 10Gbps and 20km transmission distance with SMF. The transceiver consists of three sections: a DFB laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements. The transceivers are compatible with SFP Multi-Source Agreement and SFF-8472 digital diagnostics functions.
Optical characteristics
|
|
Unit |
Values |
|
Operating Reach |
m |
10K |
|
Transmit |
||
|
Center wavelength (range) |
nm |
1260 -1355 |
|
Side Mode Suppression Ratio (min) |
dB |
30 |
|
Launched power |
||
|
– maximum |
dBm |
+0.5 |
|
– minimum |
dBm |
-8.2 Notes1 |
|
OMA |
dBm |
-5.2 |
|
OMA-TDP (min) |
dBm |
-6.2 |
|
Transmitter and dispersion penalty |
dB |
0 Notes4 |
|
Average launch power of OFF transmitter (max) |
dBm |
-30 |
|
Extinction ratio (min) |
dB |
3.5 Notes2 |
|
RIN12 OMA (max) |
dB/Hz |
-128 |
|
Optical Return Loss Tolerance (min) |
dB |
12 |
|
Receiver |
||
|
Center wavelength (range) |
nm |
1260-1355 |
|
Receive overload (max) in average power1 |
dBm |
0.5 |
|
Receive sensitivity (min) in average power1 |
dBm |
-14.4 Notes3 (10km) |
|
dBm |
-13.4 Notes3 (20km) |
|
|
Receiver sensitivity (max) in OMA (footnote 2) |
dBm |
-12.6 Notes3 (10km) |
|
dBm |
-11.6 Notes3 (20km) |
|
|
Receiver Reflectance (max) |
dB |
-12 |
|
Stressed receiver sensitivity (max) in OMA2 |
dBm |
-10.3 |
|
Vertical eye closure penalty (min)3 |
dB |
2.2 |
|
Stressed eye jitter (min)2 |
UIp-p |
0.7 |
|
Receive electrical 3dB upper cutoff frequency (max) |
GHz |
12.3 |
|
Receiver power (damage, Max) |
dBm |
1.5 |
Electrical characteristics
|
Parameter |
Symbol |
Min. |
Typical |
Max |
Unit |
Notes |
|
Data Rate |
|
- |
10.3125 |
- |
Gbps |
|
|
Power Consumption |
|
- |
1200 |
1500 |
mW |
|
|
Transmitter |
||||||
|
Single Ended Output Voltage Tolerance |
|
-0.3 |
- |
4.0 |
V |
|
|
C common mode voltage tolerance |
|
15 |
- |
- |
mV |
|
|
Tx Input Diff Voltage |
VI |
400 |
|
1600 |
mV |
|
|
Tx Fault |
VoL |
-0.3 |
|
0.4 |
V |
At 0.7mA |
|
Data Dependent Input Jitter |
DDJ |
|
|
0.10 |
UI |
|
|
Data Input Total Jitter |
TJ |
|
|
0.28 |
UI |
|
|
Receiver |
||||||
|
Single Ended Output Voltage Tolerance |
|
-0.3 |
- |
4.0 |
V |
|
|
Rx Output Diff Voltage |
Vo |
300 |
|
850 |
mV |
|
|
Rx Output Rise and Fall Time |
Tr/Tf |
30 |
|
|
ps |
20% to 80% |
|
Total Jitter |
TJ |
|
|
0.70 |
UI |
|
|
Deterministic Jitter |
DJ |
|
|
0.42 |
UI |
|
What is the difference between SFP and SFP+ 10G?
SFP and SFP+ are both small form-factor pluggable transceivers used in networking equipment for transmitting data over fiber optic cables. The main difference between the two is their speed.
SFP modules have a data rate of up to 1Gbps, while SFP+ modules have a data rate of up to 10Gbps. This means that SFP modules are typically used for slower connections such as 10/100/1000 Ethernet, while SFP+ modules are used for higher speed connections such as 10 Gigabit Ethernet.
Another difference is that SFP modules are typically used for shorter distances, while SFP+ modules can be used for longer distances. SFP modules are designed for distances of up to 550 meters over multi-mode fiber and up to 10 kilometers over single-mode fiber. SFP+ modules, on the other hand, can transmit data over distances of up to 40 kilometers over single-mode fiber.
In terms of physical size, SFP and SFP+ modules are almost identical, with the main difference being the number of electrical contacts. SFP modules have 20 contacts, while SFP+ modules have 30 contacts.
