The HEP5800-08P series products are highly integrated, medium-capacity box-type EPON OLT equipment for operators, ISPs, enterprises and campus applications. The product follows the IEEE802.3ah technical standard and meets the requirements for EPON OLT in 《YD/T 1475-2006 Access Network Technical Requirements - Ethernet-based Passive Optical Network (EPON)》 and 《China Telecom EPON Equipment Technical Requirements 3.0》Equipment-related requirements, good openness, strong compatibility, high reliability, and complete software functions, can be widely used in operator FTTH access, private network access, government and enterprise park access, campus network access and other access network construction .
|
Model |
HEP5800-08P |
|
product configuration |
8*GEPON SFP，4*10GE/GE SFP，4*10/100/100 BaseT，AC/DC dual power supply optional |
|
AC power module |
NPAC220-50W-1 |
|
DC power module |
NPDC48-48W-1 |
|
Physical Interface |
1RU19 inch Cassette; |
|
1+1 Power redundancy； |
|
|
EPON Port: 8 EPON ports, type GEPON SFP; |
|
|
Upstream Electrical Ports: 4 gigabit electrical ports, the gigabit electrical ports can be adapted to 10/100/1000M, type RJ45; |
|
|
Uplink Optical Ports: 4 10Gigabit optical ports, 10 Gigabit optical ports support Gigabit optical, type SFP/SFP+/LC; |
|
|
Console Port: management serial port, used for device command line management, type RS232; |
|
|
MGMT Port: out-of-band management port, used for device Telnet/SSH/WEB login control, type RJ45; |
|
|
USB Port: USB port, used for device software upgrade, configuration upload and download, authorization ukey, type USB2.0; |
|
|
Type C Interface: Type-C management interface, used for device command line configuration management, type Type C; |
|
|
RST Port: reset port, used for manual reset and restart of the device; |
|
|
Mechanical structure |
Chassis shell: metal shell, air cooling; |
|
Power fan: Modular design of power supply, support hot swap. two fixed fans; |
|
|
Chassis size: Dimensions (length*width*height) (mm) 440*260*44; |
|
|
Installation method: standard 19-inch 1U rack-mounted installation; |
|
|
Features |
Support 1:64 split ratio, the whole machine supports 512 ONU access; |
|
Support IGMP Snooping and IGMP Proxy of IGMPV1, V2, and V3; |
|
|
Support DHCP Option82 and PPPOE+ upload physical user information； |
|
|
Support ACL security filtering mechanism, provide security control functions based on MAC, IP, L4 port and port level; |
|
|
Support SP/WRR/SP+WRR priority algorithm to ensure the transmission of various priority service flows on demand; |
|
|
Support multi-port mirroring analysis function, support mirroring analysis based on business flow; |
|
|
Support static and flexible QinQ functions; |
|
|
Support IPv4/IPv6 dual protocol stack platform, support IPv4/IPv6 static routing; |
|
|
Support IPv4/IPv6 dual protocol stack platform, support RIP/OSPF and other routing protocols; |
|
|
Support multiple link redundancy and network redundancy protocols such as VRRP/ERPS/MSTP/FlexLink/MonitorLink; |
|
|
Support Ethernet OAM 802.3ag (CFM), 802.3ah (EFM) and other Ethernet link detection mechanisms; |
|
|
Support remote user authentication based on Tacacs+/Radius, support Local local user authentication; |
