4 Ports Media Converter
The fast Ethernet media converters, featuring 1-fiber transmission with Wavelength Division Multiplexing(WDM) technology, utilize fiber optics to extend the physical distance range of typical Ethernet link to 20km-100km.It’s often applied in school, cyber bars, offices, and telecommunication networks.
|
Standard |
IEEE802.3 (10BASE-T), IEEE802.3u 100BASE-TX/FX (Fast-Ethernet), IEEE802.3x (Flow Control), IEEE802.1q, IEEE802.1p QoS, IEEE802.1d |
|
Spanning Tree |
|
|
10/100BASE-T |
STP or UTP Category 5/5e/6 cable (Max. 100m) |
|
100BASE-FX |
9/125um singlemode fiber cable (20/40/60/80/100km) |
|
Conversion Mode / Delay Time |
Store-and-Forward < 10us |
|
Flow control |
Full duplex-flow control, Half duplex-back pressure |
|
RJ-45 Port |
Auto-MDI/MDIX |
|
Fiber Connector |
SC standard, ST/FC optional |
|
Wavelength |
1310/1550nm |
|
Dimensions |
70mm(W) x 93mm(L) x 25mm(H) |
|
Weight |
Net weight : 0.20kg; Gross weight : 0.35kg |
|
Input Voltage |
DC 5V1A with External power adapter |
|
Power Consumption |
<2.5W |
|
MTBF |
50,000 hours |
|
BER |
<1/1000000000 |
|
MAC Address Table |
2K |
|
Buffer Size |
512K |
|
Operating Temperature |
0℃~50℃ |
|
Storage Temperature |
-40℃~70℃ |
|
Storage Humidity |
5%~90% non-condescending |
