MPO TO MPO Patch Cord
MPO Fiber Patch cable/trunk cable is terminated with MPO connector on both ends. MPO Patch cable/trunk cables connect MPO modules together as a permanent link. The Patch cable/trunk cables are available with 12, 24, 48,60,72 ,96,144fibers. Support speeds up to 10/40/100Gbps data center solutions. They are typically adopted to interconnect cassettes, panels or ruggedized MPO fan-outs, and to facilitate rapid deployment of high-density backbone cabling in data centers and other high fiber environments. Besides, MPO also provides much flexibility and convenience once you have to change the connector style in the patch panels. Instead of changing the connector on the cable trunk, just installing a new cassette with the new connector style on the cross-connect side of the patch panel.
|
Spec items. |
Single mode (APC 8-degree polished) |
Multimode (PC Flat polish) |
|
Insertion loss (MPO) |
Standard loss：≤0.75dB(max), ≤0.35dB(Typical) |
Standard loss：≤0.6dB(max), ≤0.35(Typical) |
|
(IEC 61300-3-34) |
Super Low loss：≤0.35dB(max), ≤0.20dB(Typical) |
Super Low loss：≤0.35dB(max) , ≤0.20dB(Typical) |
|
Return loss(MPO) |
≥60dB（8degree polishing） |
≥25dB |
|
Durability |
<0.3dBtypical change, 200 matings |
|
|
Interchangeability |
≤0.2dB |
|
|
Tensile strength |
>70N |
|
|
Operating Temperature |
-40 to + 85°C |
|
|
Fiber Count |
OD(mm) |
Minimum allowable |
minimum allowable |
Minimum Bending |
|
Tensile Strength (N) |
Crush Load(N/100mm) |
Radius(MM) |
||
|
12 |
3.0±0.15 |
Short-term: 180； |
Short-term: 500； |
Static：10D |
|
Long-term: 90 |
Long-term: 150 |
Dynamic：20D |
