■1GE 1FE WIFI is designed as HGU (Home Gateway Unit) in deferent FTTH solutions; the carrier-class FTTH application provides data service access.
■1GE 1FE WIFI is based on mature and stable, cost-effective XPON technology. It can switch automatically with EPON and GPON mode when it access to the EPON OLT or GPON OLT.
■1GE 1FE WIFI adopts high reliability, easy management, configuration flexibility and good quality of service (QoS) guarantees to meet the technical performance of the module of China Telecom EPON CTC3.0.
■1GE 1FE WIFI is compliant with IEEE802.11n STD, adopts with 2x2 MIMO, the highest rate up to 300Mbps.
■XPON 1GE 1FE WIFI are fully compliant with technical regulations such as ITU-T G.984.x and IEEE802.3ah.
■XPON 1GE 1FE WIFI is designed by Realtek chipset 9602C
|
Model |
H202-1 |
|
PON interface |
1 G/EPON port(EPON PX20+ and GPON Class B+) |
|
Upstream: 1310nm; Downstream: 1490nm |
|
|
SC/UPC connector |
|
|
Receiving sensitivity: ≤-27dBm |
|
|
Transmitting optical power: 0~+4dBm |
|
|
Transmission distance: 20KM |
|
|
LAN interface |
1x10/100/1000Mbps and 1x10/100Mbps auto adaptive Ethernet interfaces. Full/Half, RJ45 connector |
|
WIFI Interface |
Compliant with IEEE802.11b/g/n |
|
Operating frequency: 2.400-2.4835GHz |
|
|
support MIMO, rate up to 300Mbps |
|
|
2T2R,2 external antenna 5dBi |
|
|
Support: Multiple SSID |
|
|
Channel:13 |
|
|
Modulation type: DSSS、CCK and OFDM |
|
|
Encoding scheme: BPSK、QPSK、16QAM and 64QAM |
|
|
LED |
7 LED, For Status of POWER, LOS, PON, LAN1~LAN2, WIFI, WPS |
|
Push-Button |
4, for Function of Power on/off, Reset, WPS, WIFI |
|
Operating condition |
Temperature : 0℃～+50℃ |
|
Humidity :10%～90%（non-condensing） |
|
|
Storing Condition |
Temperature : -40℃～+60℃ |
|
Humidity :10%～90%（non-condensing） |
|
|
Power supply |
DC 12V/1A |
|
Power Consumption |
<6W |
|
Net Weight |
<0.4kg |
|
Feature |
Supports Dual Mode (can access GPON/EPON OLT). |
|
Supports GPON G.984/G.988 standards |
|
|
Support 802.11n WIFI (2x2 MIMO) function |
|
|
Support NAT, Firewall function. |
|
|
Support Flow & Storm Control , Loop Detection, Port Forwarding and Loop-Detect |
|
|
Support port mode of VLAN configuration |
|
|
Support LAN IP and DHCP Server configuration |
|
|
Support TR069 Remote Configuration and WEB Management |
|
|
Support Route PPPoE/IPoE/DHCP/Static IP and Bridge mixed mode |
|
|
Support IPv4/IPv6 dual stack |
|
|
Support IGMP transparent/snooping/proxy |
|
|
In compliant with IEEE802.3ah standard |
