FC2001 1GE XPON GPON EPON ONU
Overview
FC2001 is one of the latest G/EPON passive optical network communication terminal series, the product provides one 10/100/1000M RJ45 interface, one optical fiber access, suitable for home and small business users, which can well meet the FTTH high-speed data transmission applications.
Interface
1 * G/EPON interface: SC/UPC/APC interface, complying with GPON and EPON standards
1 * Ethernet interface: 10 MBPS / 100 MBPS / 1000 MBPS, RJ - 45, IEEE802.3-2005 standard
Connection
Model: FC2001
Specification
|
Attributes |
Description |
|
|
Interface |
1*RJ45 (GE)+1*SC/UPC (or SC/APC) |
|
|
LED |
Power +PON/LOS+LAN |
|
|
SRAM & Flash |
SRAM: Embedded SDRAM; Flash: 8MB |
|
|
Power Supply |
12V/0.5A |
|
|
Size and Weight |
79.5mm*75mm*21mm (L*W*H), 0.05kg |
|
|
Power Consumption |
5W |
|
|
Environment Standard |
Operating Temperature: -5~45℃ Operating Temperature: -20~70℃ Operating Humidity: 5%~95% (non-condensing) |
|
|
Product Interface |
Ethernet Port |
Ethernet port-based VLAN tags and tag removal VLAN transparent and aggregation MAC address learning 10/100/1000Mbps Auto negotiation |
|
XPON Feature |
ITU-T G.984.1-4; IEEE 802.3ah 15 TCONTs /256GEM ports 8 Egress queues per TCONT at least VLAN/ priority/VEIP gem mapping mode SN/LOID/SN+ Password authentication Performance monitoring: eth/Gem port Dying gasp |
|
|
L2 Feature |
MAC learning (SVL)/aging Support max frame length to 1518 bytes VLAN tagging for untagged packets Support VLAN 1-4094 VLAN transparent / translation |
|
|
Multicast |
IGMP v2 (RFC 2236) and IGMP v3 (RFC 3376) IGMP snooping |
|
|
Management |
OMCI/WEB UI SSH Management with CLI commands Dual-system software backup and rollback |
|
