10Gigabit 40G 100G Uplink Layer 3 Switch
HS5863-24X2C switch is a high-performance full 10G access, 40G and 100G uplink core routing Layer 3 switch product independently developed by the company. It can not only meet the high-density and high-bandwidth network application requirements of the next-generation enterprise network, data center and metropolitan area network, but also meet the application requirements of telecom network operators or campus Ethernet aggregation layer or access layer, and can also be used as a data center connection layer. The entry layer and the core layer of small and medium-sized enterprises provide rich server access solutions for the data center.
|
Model |
HS5863-24X2C |
|
product configuration |
24*10G SFP+，2*40 QSFP/2*100G QSFP28，1+1 pluggable power supply, AC/DC optional |
|
AC power module |
NPAC220/96W-1 |
|
DC power module |
|
|
Physical Interface |
10 Gigabit Optical Ports: 24 *10Gigabit optical ports, 10Gigabit optical ports can be adaptively connected to Gigabit optical ports, type SFP/SFP+/LC; |
|
Uplink Optical Ports: 2 *40G uplink optical ports, type QSFP; or 2 *100 uplink optical ports, type QSFP28; |
|
|
Console Port: management serial port, used for command line management, type RS232; |
|
|
MGMT Port: out-of-band management port, used for Telnet/SSH/WEB login control, type RJ45; |
|
|
Mechanical structure |
Chassis shell: metal shell, air-cooled heat dissipation; |
|
Power Supply Fan: modular design of power supply and fan, support hot swap, support fan speed control and alarm detection; |
|
|
Chassis size: Dimensions (length*width*height) (mm) 440*320*44; |
|
|
Installation method: standard 19-inch 1U rack-mounted installation; |
|
|
Features |
Support 24 100/1000M SFP (or SFP-1000BaseT RJ45 ) access and 4 10G SFP+ uplink port (1000M/10G) |
|
Support the default 100M,1000M SFP,the SFP-1000BaseT RJ45 and 10G SFP+ hot plug |
|
|
Support full rate, full-duplex non-blocking forwarding at each port |
|
|
Modular design of the whole machine, pluggable design of fans and power components; |
|
|
Support WEB ,and SNMP management (optional):VLAN,STP/RSTP,Trunk port aggregation, IGMP,port Mirroring,port isolation,broadcast control,loop detection,QinQ, etc |
|
|
Support DHCP,PPPoE,ACL,LLDP |
|
|
Standard 1U rack ,internal double cooling fan,better for heat dissipation,work stable |
|
|
Support 16K MAC learning, 12Mbit storage and forward cache space,128G back plane bandwidth,9KByte Large frame forwarding |
|
|
All optic ports, strengthen the an-interference ability |
|
|
Support SP/WRR/SP+WRR priority algorithm to ensure the transmission of various priority service flows on demand; |
|
|
Support the AC dual redundant power supply hot backup and DC12V/5A spare battery power |
|
|
Support multi-port mirroring analysis function, support mirroring analysis based on service flow; |
|
|
Support static and flexible QinQ function; |
|
|
Support policy-based IPv4/6 unicast routing, and support flexible forwarding policies; |
|
|
Support CLI command line management based on serial port, Telnet, SSHv2; |
|
|
Support RFC1213 SNMP network management; |
|
|
Support configuration management based on WEB page |
|
|
working environment |
Working temperature: -15~+55℃ Storing temperature: -40~+85℃ Relative humidness: 10%~90 %(non-condensing) |
|
Power Supply |
Power Supply Specifications: 1+1 redundant power supply, AC/DC optional; |
|
Input Power: AC: input 90～264V, 47～67Hz |
|
|
Power Consumption of the whole machine: full load power consumption ≤ 22W, idle power consumption ≤ 13W; |
