25G SFP28 ER 1310nm 40KM LC Optical Transceiver
It is an SFP28 ER module used for duplex fiber optic data communication, supporting a 25.78 Gb/s 40Km data link. The transmitter uses high-performance 1310nm EML, and the receiver is an avalanche photodiode (APD) installed in the optical head and limiting post amplifier IC.
Send Inquiry
Product Introduction
Features:
- SFF-8472 compliant monitoring interface
- Single+3.3V power supply
- Hot-Pluggable SFP footprint
- Built in dual CDR
- Supports data rates up to 25G
- 40 kilometers on 9/125um SMF
- Extremely low EMI and excellent ESD protection
- RoHS compliant products
- DFB+PIN; Low power consumption<2W
- Applied to metropolitan and long-distance networks
- Fully compatible with over 100 suppliers
- Digital diagnostic capability
- Level 1 Laser Safety Certification
- A cost-effective SFP28 solution that enables higher port density and greater bandwidth
- Shell working temperature: commercial: 0~+70 ℃, expansion: -10~+80 ℃, industrial: -40~+85 ℃
|
Form Factor |
SFP28 |
|
Data Rate |
25Gbps |
|
Connector Type |
LC Duplex |
|
Wavelength |
1310nm |
|
Distance |
40KM@OS2 with FEC |
|
Cable Type |
OS2 SMF |
|
Transmitter Type |
DFB |
|
Receiver Type |
PIN |
|
TX Power |
-3~6dBm |
|
RX Sensitivity |
-18dBm |
|
Power Consumption |
<2W |
|
Operating temperature |
0~70°C(Commercial) |
|
DDM/DOM |
Support |
|
Certification |
CE/FCC/RoHS/ISO9001 |
|
Protocol |
IEEE 802.3ba, SFP28 MSA |
|
BER |
1E-12 |
|
Warranty |
3YEARS |
