SFP-25G-SR 25GBASE SR SFP28 850nm 100m LC
It is an SFP28 module designed for 25Gb/s data rate on multimode fiber. It is equipped with SFP+20 pin connectors for hot swappable functionality. The digital diagnosis function can be achieved through I2C. It has a built-in dual clock and data recovery (CDR).
Send Inquiry
Product Introduction
Features:
- Supports up to 25.78Gbps bit rate
- Hot-pluggable SFP+ footprint
- 850nm VCSEL laser and PIN photodiode
- Maximum link length of 70m on OM3 MMF and 100m on OM4 MMF
- Compliant with RoHS directives
- Single+3.3V power supply
- Power dissipation < 1W
- Real time digital diagnostic monitoring
- Working shell temperature: Standard: 0 to+70 ° C
- Digital diagnostics functions are available via the I2C interface
|
Form Factor |
SFP28 |
|
Data Rate |
25Gbps |
|
Connector Type |
LC Duplex |
|
Wavelength |
850nm |
|
Distance |
100m@OM4 |
|
Cable Type |
OM3/OM4 MMF |
|
Transmitter Type |
VCSEL |
|
Receiver Type |
PIN |
|
TX Power |
-9.1~2.4dBm |
|
RX Sensitivity |
-11dBm |
|
Power Consumption |
<1W |
|
Operating temperature |
0~70°C(Commercial) |
|
DDM/DOM |
Support |
|
Certification |
CE/FCC/RoHS/ISO9001 |
|
Protocol |
IEEE 802.3ba, SFP28 MSA |
|
BER |
1E-12 |
|
Warranty |
3YEARS |
